DaLian Deutz F4M2011 Pump Drive Engine

Dalian Deutz F4M2011 Pump Drive Engine uses a 4 Cylinder design, a 4 Cylinder engine is usually suitable for larger vehicles or applications that require higher torque and power output.

F4M2011 has a displacement of 3.1 L, larger displacement means better acceleration performance and handling stability, especially suitable for heavy-duty or high-load working environments.

The Engine has a maximum power output of 29 kW, enough to drive large vehicles or provide high performance, which is important for applications that require quick acceleration or long distance runs.

We provide all customers with full life cycle services from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from troubleshooting to maintenance technical support.

Advantages of DaLian Deutz F4M2011 Pump Drive Engine

  • F4M2011 Pump Drive Engine adopts advanced combustion technology and fuel management system, which can effectively control fuel consumption. Compared with other engines of the same level, it can achieve higher fuel economy and lower operating costs under the same workload.

  • The Engine is assembled with Deutz brand technology and craftsmanship, as well as high-quality components, ensuring its high reliability and long-lasting durability. It has undergone strict testing and quality control, and can adapt to various harsh working conditions and environments, providing stable and reliable performance.

  • The F4M2011 Pump Drive Engine is designed with ease of maintenance in mind, facilitating routine repair and maintenance operations. It adopts a modular design, which makes the parts easier to remove and replace, reducing maintenance time and cost. In addition, Detz also provides a wide range of after-sales service and spare parts support, which is convenient for users to carry out maintenance and maintenance work.

  • The Engine uses advanced combustion technology and emission control system to meet strict emission standards. It uses high-efficiency turbochargers and advanced injection systems to make combustion more complete and reduce pollutant emissions.

Technical Specifications

Engine Type:4 Cylinders, in Line
Displacement:3.1 L
Rated Power / Speed:29 kW @ 1500 RPM
Rotation (looking at Flywheel):CCW
Exhaust Emission Standard:Stage 2
Compression Ratio:19
Injection System:single injection pumps
Mean effective pressur:7.95 PRP
Piston Speed:5.6 m/s
Bore*Stroke:94 mm *112 mm
Lead Time:15-30 Working Days
Payment Terms:T/T ,L/C

Coming Soon

Coming Soon

Engine Model

No of cylinders



F2M201121.6 L1500 RPM
F3M201132.3 L1500 RPM
F4M201143.1 L1500 RPM
BF4M201143.1 L1500 RPM
F2M2011-A21.6 L1800 RPM
F3M2011-A32.3 L1800 RPM
F4M2011-A43.1 L1800 RPM
BF4M2011-A43.1 L1800 RPM
BF4M2011C43.109 L1500 RPM
BF4M2011C-A43.109 L1800 RPM

General Information of Dalian Deutz F4M2011 Pump Drive Engine

Engine ModelF4M2011Exhaust Emission StandardStage 2
AspirationnaturalSpeed1500 RPM
Engine Type4 Cylinders, in LineCompression Ratio19
Injection Systemsingle injection pumpsMean Effective Pressur7.95 PRP
Displacement3.1 LPiston Speed5.6 m/s
Bore*Stroke94 mm *112 mmRotation (looking at Flywheel)CCW

Technical Specification of Dalian Deutz F4M2011 Pump Drive Engine

Fan Reduction0.4 kW
Max. Suction Head of Fuel Feed Pump3 m
Max. Intake Depression20 mbar
Max. Exhaust Back Pressure30 mbar
Max. Exhaust Gas Temperature599 ℃
Exhaust Flange/Fipe Diameter45 mm
Voltage12 V
Starter3 kW
Alternator Output (A)55
Batteries (Ah)1*66

Coming Soon

Coming Soon

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
